Current Position: Home » Product » SST-Porous®Oxygen sensor eptfe tube (typical application: automobile oxygen sensor, motorcycle oxygen sensor, etc.)
Protective Vents
SST-Porous®Oxygen sensor eptfe tube (typical application: automobile oxygen sensor, motorcycle oxygen sensor, etc.)
  • SST-Porous®Oxygen sensor eptfe tube (typical application: automobile oxygen sensor, motorcycle oxygen sensor, etc.)
  • SST-Porous®Oxygen sensor eptfe tube (typical application: automobile oxygen sensor, motorcycle oxygen sensor, etc.)

SST-Porous®Oxygen sensor eptfe tube (typical application: automobile oxygen sensor, motorcycle oxygen sensor, etc.)

SST-Porous ®oxygen sensor vent tube is made by 100% PTFE fine powder. It has stable size and can work for a long time at – 200 ~ + 260 ℃. It has the characteristics of high filtration efficiency, high water pressure resistance, stable and good permeability, excellent flexibility and high mechanical strength. It is especially suitable for the ventilation and protection of tubular electronic components such as oxygen sensor.

Product Overview

Porous-Tech®PTFE  porous membrane (including:tube type and sheet type)having the characteristic of chemical innert, hydrophobic and air permeable.  can be used for a long time at operating temperature from 60~260℃,  siutatble for gas sensr.  Smart Membrane® porous membrane structure allows gas to pass through the sensor while retaining liquid or limiting liquid penetration.

Charateristics & Features

Porous-Tech® PTFE porous air breather tube are mainly used for oxygen sensor.


Porous-Tech® ePTFE air breathable tube has the characteristics of high filtration efficiency, high water pressure resistance,  good air permeability, excellent flexibility, high mechanical strength, etc., especially suitable for the ventilation and protection of tubular electronic components such as oxygen sensors.  Additionally, The Porous Tech® ePTFE tube is easy to install and can be molded manually or automatically.

In addition to the eptfe breathable tube, the Porous Tech® PTFE  commonly used for oxygen sensors also includes sheet-type eTFE microporous membrane (thickness 0.1~0.5mm, breathable capacity 100~600ml/cm2/min@7kPa, protection class, IPX8).



Description of physical parameters

1、Excellent high and low temperature resistance

operating temperature: – 60 ~ 260

2Excellent resistance to strong acid and alkali

PTFEPVDFAl2O3



3High filtration accuracy and controllable micropore size

averange porous diameter:0.1~0.6μm



4、ID and OD can be customized

Diameter from 3~100mm( for oxygen sensor the common size:OD 16mm/ID 14mm and OD 14mm ID 12mm)

5Excellent waterproof, dustproof, air permeability

Airflow from 100~600ml/cm2/min@7mbar,IP rate up to IP68

Typical Applicaiton

Automotive oxygen sensor, motorcycle oxygen sensor  cable protection etc
